Pedestrian Fence
A stylish, strong and customisable fence which beautifies your perimeter also making it more secure
Pedestrian Fence
A stylish, strong and customisable fence which beautifies your perimeter also making it more secure
features

Aesthetic
The customisable decorative patterns on the fence give an eloquent look to the fence system.
Colours Available
Colours Available


Strong & Rigid
The unique twin wire welded structure made with 8 mm diameter wires imparts high strength & rigidity to the fence.

Long Life
Pre galvanized wire + Eco Friendly thermoplastic coating provides excellence corrosion resistance thereby extending the life of the panel by upto 10 years
Applications

Boundary Fencing

Pedestrian Protection

Road Medians
Standard Specifications
Panel Specification | |||||
Height | Width | Mesh Size | Wire Diameter | Coating | |
Vertical | Horizontal | ||||
1200 mm | 2015 mm | 65×200 | 6 mm | 8 mm | PPC/TPC |
1886 mm | 2015 mm | 65×200 | 6 mm | 8 mm | PPC/TPC |
Post Specification | |||
Cross Section (with thickness) | No. of Clamps required | Height (above GL) | Coating |
60x60x1.5 mm | 4 x M10 x 120 | 130x130x8.0mm | PPC/TPC |
60x60x1.5 mm | 4 x M10 x 120 | 130x130x8.0mm | PPC/TPC |
